The DYS-03C 316 Stainless Steel bag filter vessels are designed to work up to a fluid flow rate of 15 gallon per minute. These heavy duty vessels are available in different options of inlet types and
nozzle configurations. The vessels accommodate the standard BG03 series bag filters that Dynalene offers. The maximum pressure rating on our standard vessel design is 150 PSI and ASME code stamp can be provided on all of our products.
- Up to 15 GPM flow rate capacity
- 150 PSI pressure rating. ASME code stamping available
- 316 Stainless Steel material of construction
- 250°F (121°C) Maximum operating temperature
- Easy to use manual lid lift with swing bolt.
- FNPT or flange connection configurations
- Includes Buna N gasket
- Compatible with glycol based heat transfer fluid
- Water filtration
- Glycol filtration
